一、安装etcd

[root@k8s-master ~]# yum install etcd -y

[root@k8s-master ~]# vim /etc/etcd/etcd.conf

6行：ETCD_LISTEN_CLIENT_URLS="http://0.0.0.0:2379"

21行：ETCD_ADVERTISE_CLIENT_URLS="http://10.0. 0.11:2379"

启动

[root@k8s-master ~]# systemctl start etcd.service

查看

etcdctl -C http://10.0.0.11:2379 cluster-health



二、安装k8s

[root@k8s-master ~]# yum install kubernetes-master.x86_64 -y


配置k8s

vim /etc/kubernetes/apiserver

8行:  KUBE_API_ADDRESS="--insecure-bind-address=0.0.0.0"

11行：KUBE_API_PORT="--port=8080"

14行: KUBELET_PORT="--kubelet-port=10250"

17行：KUBE_ETCD_SERVERS="--etcd-servers=http://10.0.0.11:2379"

23行：KUBE_ADMISSION_CONTROL="--admission-control=NamespaceLifecycle,NamespaceExists,LimitRanger,SecurityContextDeny,ResourceQuota"

​

vim /etc/kubernetes/config

22行：KUBE_MASTER="--master=http://10.0.0.11:8080"

​

systemctl enable kube-apiserver.service

systemctl restart kube-apiserver.service

systemctl enable kube-controller-manager.service

systemctl restart kube-controller-manager.service

systemctl enable kube-scheduler.service

systemctl restart kube-scheduler.service



查看组件状态

[root@k8s-master ~]# kubectl get componentstatus
NAME                 STATUS    MESSAGE             ERROR
controller-manager   Healthy   ok
scheduler            Healthy   ok
etcd-0               Healthy   {"health":"true"}
